Updated facade guidance aims to clarify material use

With changes to the Building Regulations on the use of combustible materials in England having proved confusing, two industry associations offer up-to-date guidance for the construction sector.

Although Building Regulation 7 may seem simple, modern building envelopes are not.

Following revisions to the Building Regulations in 2018, which in effect banned the use of combustible materials in the facade of certain buildings, the Centre for Window and Cladding Technology (CWCT) and the Society of Facade Engineering (SFE) quickly realised that additional guidance was needed to enable consistent interpretation and application.

With limited exemptions, the regulation requires all materials in the external walls of relevant high-rise buildings – broadly speaking those with a storey above 18m where there is sleeping accommodation, such as residential blocks, student halls and hotels – to achieve class A2-s1, d0 or better, as defined in BS EN: 13501-1: 2018.

Key to Regulation 7 are the exemptions provided. These are a list of materials that do not have to be class A2-s1, d0 and are essential for achieving other key performance criteria, such as thermal performance and weathertightness. Whilst the list of exemptions appears comprehensive, they still do not take the complexity of modern facades into full account. As a result, ambiguity and uncertainty remain over the combustible materials that may or may not be used, and in what circumstances it may be appropriate to use them.

The CWCT and the SFE therefore assumed responsibility for publishing guidance on this subject, which they did in 2020, revising this last July to reflect the changes made to Regulation 7 in 2022. This guidance is freely available to download from the CWCT website at www.cwct.co.uk/pages/cwct-sfe-fire-guidance

The work involved collaboration between facade engineers, fire engineers, architects, building control professionals, surveyors and manufacturers. The aim is to provide consistent, pragmatic guidance that the whole construction industry can adopt.

Without a consistent approach, there is uncertainty about the materials that can be used and the potential for conflict between different parties. As such, the different sectors of the industry need to familiarise themselves with this guidance. However, given the fragmented nature of the process for designing, constructing, assessing and approving external walls, this is a challenge in itself. Our understanding is that this guidance is not well known outside of the facade industry and we are keen to change this.

Due to the prescriptive nature of the Building Regulations, one of the key challenges faced by the construction industry in interpreting Regulation 7 has been the terminology that is used.

Is a material simply defined by its structure and composition, or does it also depend on its function? This is important, as it potentially affects which materials can and cannot be used.

If a membrane material is used to seal a window opening, for instance, is it defined as a membrane or as a seal? If it is considered as a membrane, guidance in Approved Document B recommends that it achieves a reaction to fire of class B-s3, d0. However, if it is defined as a seal then Approved Document B imposes no specific restrictions.

To understand the significance of this, we need to look beyond fire performance. A seal around the perimeter of the window is also vital in terms of preventing water ingress and minimising air leakage. Yet its performance depends not only on the material used but also the quality of installation. It is therefore important to recognise practical considerations as well when establishing whether materials are appropriate.

When the CWCT and SFE first published their guidance, class B membrane products lacked the flexibility needed to support straightforward installation. This prompted the guidance’s conclusion that a membrane material sealing a window to a back wall can be considered a seal.

Were this not the case and it was instead considered a membrane – and therefore subject to the class B-s3, d0 recommendation in Approved Document B – the resultant lack of suitable products could have resulted in significant problems for overall building performance. Our interpretation has been widely adopted and is just one example of the pragmatic advice provided by the guidance.

However, although the exemptions to Regulation 7 acknowledge the vital role that certain combustible materials play in the performance of modern facades, it is important to recognise that the industry has responded to the de facto ban by developing new materials that do comply with the regulation.

Where such materials do not compromise other aspects of performance, it will almost always be appropriate to use them instead of a more combustible alternative.

Work on this guidance is ongoing: it does not cover every situation, and government regulation and policy continues to evolve.

The guidance is therefore a live document. CWCT and SFE welcome feedback (email cwct@cwct.co.uk) on the interpretations our guidance provides, or any conflicts that users experience in applying them, as well as suggestions for materials or systems not covered. This is all part of the collaborative approach taken to producing this key guidance.

For more information, go to www.cwct.co.uk
